ER603WP-4G-Outdoor
Omada 4G Cat4 N300 Outdoor PoE Gateway
- 4G Cat4 up to 300 Mbps*
- Wi-Fi 4, Support 150 Mbps on 2.4 GHz†
- 3× Gigabit WAN/LAN Ports (2× PoE Out, 1× PoE In)
- 1× Nano SIM Card Slot
- 802.3at/bt PoE/Passive PoE/DC Power Supply
- IP55 Weatherproof & 4 kV Lightning Protection
- Load Balancing between 4G and Ethernet WAN
- IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE§ VPN
- Centralized Cloud Management△
Simplify Outdoor Surveillance
with 4G Plug-and-Play
Omada 4G Cat4 N300 Outdoor PoE Gateway
ER603WP-4G-Outdoor
4G Cat4
up to 150 Mbps*
Stable Connectivity up to 300 Mbps on 2.4 GHz†
802.3af/at/bt PoE/12V DC (Compatible with Solar Power System)
3× Gigabit Ports (2× PoE Out, 1× PoE In) & 1× Nano SIM Card Slot
Centralized Cloud Management
IPSec/GRE§/ WireGuard/PPTP/ L2TP VPN & OpenVPN
4G and Ethernet WAN for Auto-Backup with Load Balancing
IP55 Weatherproof
All-in-One Solution for Outdoor Connectivity
By integrating 4G network access, Wi-Fi expansion, and PoE supply into a single device, Omada delivers an all-in-one solution designed for reliable remote connectivity.
Cloud-Based Controller
Internet
4G
Cloud-Access to Omada Controller
Web Browser
Omada App
Wi-Fi Camera
Omada Outdoor 4G
Wi-Fi Gateway ER603WP-4G-Outdoor
Wi-Fi Gateway ER603WP-4G-Outdoor
PoE In
DC Power
PoE In
IP Camera
Omada Outdoor AP
PoE Out※
Enable Always-On Surveillance Where You Need
With stable network and flexible deployment, it provide the wireless connectivity for cameras, achieving persistent monitoring for enhanced security beyond the reach of traditional broadband.
Street Corner
Barn/Warehouse
Farm/Ranch
Construction Site
Mine
Mobile Car/Temporary Site
Multiple Power Supply Options
Powered by PoE or DC (compatible with solar panels) to overcome mains access limitations.
or
PoE In
PoE Injector
PoE Switch
DC Power
(Compatible with Solar Power System)
Solar Panel System
or
DC Power
Easy Setup with Flexible Deployment
SIM
Plug and Play
Simply insert a Nano SlM card or plug in Ethernet for stable Wi-Fi to connect surveillance cameras via cable or wireless.
Pole/Wall-Mounting
With the included mounting kits, the compact gateway can be easily installed on a wall or pole for flexible placement.
Specially Designed Weatherproof Enclosure for Outdoors
Rated as IP55 during Ingress Protection testing, a resilient weatherproof enclosure protects the gateway against harsh outdoor conditions.
Waterproof Enclosure
No Ingress
of Dust
of Dust
Operation Temperature of -30℃ to 60℃
4kV Lightning Protection**
Easy Management with the Omada App
| 4G | |
|---|---|
| Network Type | LTE Band of EU: 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700) 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz) 3G HSPA+/HSDPA/HSUPA/WCDMA: B1/B5/B8 (2100/850/900 MHz) |
| SIM Type | 1 Nano SIM slot (CAT4 4G) |
| Frequency | • Downlink: 150 Mbps• Uplink: 50 Mbps |
| Securitate | |
|---|---|
| Access Control | • Source/Destination IP Based ACL • Stateful ACL • IPv4/IPv6 ACL • National Based ACL |
| DNS Proxy | DNSSEC, DoH, DoT, DNS Override |
| Filtrare | • Web Group Filtering§• URL Filtering• Web Security§ |
| Protecție Atacuri | • TCP/UDP/ICMP Flood Defense• Block TCP Scan (Stealth FIN/Xmas/Null)• Block Ping from WAN |
| Inspecție ARP | • Sending GARP Packets• ARP Scanning§• IP-MAC Binding• ARP Detection |
| VPN | |
|---|---|
| GRE | √ (Only in Standalone Mode) |
| VPN IPsec | • 6 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec • Failover • IKE v1/v2 • MD5, SHA1, SHA-256, SHA2-384, SHA2-256 and SHA2-512 • Authentication Algorithm NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) |
| VPN PPTP | • PPTP VPN Server• PPTP VPN Client (6)• 6 Tunnels• PPTP with MPPE Encryption |
| VPN L2TP | • L2TP VPN Server• L2TP VPN Client (6)• 6 Tunnels• L2TP over IPSec |
| OpenVPN | • OpenVPN Server • OpenVPN Client (3) • 18 OpenVPN Tunnels • "Certificate + Account" Mode • Full Mode |
| WireGuard VPN | √ |
| SD-WAN | √ (Only in Controller Mode) |
| CARACTERISTICI HARDWARE | |
|---|---|
| Interfață | 3 Gigabit WAN/LAN Ports |
| Rețea media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Butoane | Reset Button |
| Alimentator | Passive/802.3af/at/bt PoE; 12V/1A Adapter(A passive PoE adapter is provided) |
| PoE Standard | • Passive/802.3af/at/bt PoE in for port 1• Passive/802.3af/at PoE out for port 2-3※ |
| Wi-Fi Frequency & Signal Rate | 2.4 GHz: 300 Mbps |
| Flash | 128 MB NAND |
| DRAM | 256 MB DDR3 |
| LED | 4G Signal, WLAN. WAN/LAN, SYS |
| Dimensiuni (L x l x H) | 4.0 × 1.5 × 6.9 in (100.4 × 38.7 × 174.8mm)(excluding antennas) |
| Antenă | 2 internal Wi-Fi antennas2 external LTE antennas |
| Montare | Wall/Pole Mounting (Kits included) |
| Consum maxim | • 10 W without PoE• 62 W with PoE |
| Performanță | |
|---|---|
| Sesiuni Concomitente | 50,000 |
| New Sessions /Second | 2,028 |
| NAT (Static IP) | 944.785 Mbps / 939.201 Mbps |
| NAT(DHCP) | 944.545 Mbps / 927.491 Mbps |
| NAT(PPPoE) | 939.278 Mbps / 928.516 Mbps |
| NAT (L2TP) | 432.126 Mbps / 355.712 Mbps |
| NAT (PPTP) | 513.104 Mbps / 457.323 Mbps |
| 66 Byte Packet Forwarding Rate | 1,419,519 pps / 1,418,731 pps |
| 1,518 Byte Packet forwarding rate | 81,068 pps / 81,068 pps |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 192.432 Mbps• ESP-SHA256-AES256: 195.445 Mbps• ESP-SHA384-AES256: 48.55 Mbps• ESP-SHA512-AES256: 48.363 Mbps |
| GRE | • Unencrypted: 425.292 Mbps• Encrypted: 164.058 Mbps |
| WireGuard VPN | 50.175 Mbps |
| OpenVPN | 11.369 Mbps |
| L2TP VPN Throughput | • Unencrypted: 370.822 Mbps• Encrypted: 144.05 Mbps |
| PPTP VPN Throughput | • Unencrypted: 408.038 Mbps• Encrypted: 35.912 Mbps |
| Management Features | |
|---|---|
| Omada App | Yes |
| Centralized Management | • Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller |
| Cloud Access | Yes |
| Servicii | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Mentenanță | • Web Management Interface• Remote Management• Export & Import Configuration• SNMP v1/v2c/v3• Diagnostics (Ping & Traceroute)• NTP Synchronize§• Port Mirroring• CLI (only in Standalone Mode)• Syslog Support |
| Management Features | Automatic Device DiscoveryIntelligent Network MonitoringAbnormal Event WarningsUnified ConfigurationReboot ScheduleCaptive Portal ConfigurationZTP (Zero-Touch Provisioning) |
| Caracteristici Wireless | |
|---|---|
| Funcții Avansate | • WPA/WPA2 Personal, WPA/WPA2 Enterprise• Multiple SSIDs: 8 in total (8 per radio)• Rate Limit: Based on SSID/Client |
| Guest Network | Support |
| Funcții de Bază | |
|---|---|
| LAN DNS | √ |
| Tip Conexiune WAN | • Static IP • Dynamic IP • PPPoE (supports MRU Configuration) • PPTP • L2TP |
| Clonare MAC | Modify WAN Address |
| DHCP | • DHCP Server • DHCPv6 PD Server§• DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP• WAN DHCP 60 |
| Stateful ACL | √ |
| Quality of Service | √ |
| Bridge VLAN | √ |
| SMS | Receive/Send SMS |
| mDNS Repeater | √ |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Funcții Avansate | |
|---|---|
| Controlul Lățimii de Bandă | IP-based Bandwidth Control |
| Echilibrarea Traficului | • Intelligent Load Balance• Application Optimized Routing• Link Backup (Timing, Failover)• Online Detection |
| NAT | • One-to-One NAT• Multi-Net NAT• Virtual Server• Port Triggering§• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG• UPnP• Disable NAT |
| Rutare | • Static Routing• Policy Routing• RIP§• OSPF§ |
| Session Limit | IP-based Session Limit |
| AUTHENTICATION | |
|---|---|
| Web Authentication | • No Authentication• Simple Password• Hotspot (Local User / Voucher# / SMS# / Radius#)• External Radius Server• External Portal Server#• LDAP |
| Altele | |
|---|---|
| Certificări | CE, RoHS |
| Conținut Pachet | • ER603WP-4G-Outdoor• Mounting Kits• Passive PoE Adapter• Quick Installation Guide |
| Mediu | • Operating Temperature: -30°C–60 °C (-22 °F–140 °F)• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F)• Operating Humidity: 5%–95% non-condensing• Storage Humidity: 5%–90% non-condensing |
*Actual 4G downlink speeds vary between buildings. Factors affecting 4G speeds include the internet service plan, real-time network capacity, equipment and client limitations, and environmental factors.
**Protection against lightning may be achieved through proper product setup, grounding, and cable shielding. Refer to the instruction manual and consult an IT professional to assist with setting up this product.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary.
△The Omada cloud-based controller offers the Essentials version of cloud services for free, while the Standard version, which includes advanced features, requires a license.
§GRE VPN is supported only in Standalone Mode.
※The PoE-out feature requires 802.3bt PoE input.
