How to choose a suitable HDD for VIGI NVR
VIGI NVR1008H , VIGI NVR2016H-16MP-4TB , VIGI NVR4032H , VIGI NVR1004H , VIGI NVR1008H-8MP , VIGI NVR4016H , VIGI NVR1016H , VIGI NK8P-B434I , VIGI NVR2008H-8MP , VIGI NVR1008 , VIGI NK8P-B43I4 , VIGI NVR1004H-4MP , VIGI NVR2016H-16P , VIGI NVR1008H-8P , VIGI NVR1004H-4P , VIGI NK4P-T4425-2T , VIGI NVR2016H , VIGI NVR2008H-8MP-2TB , VIGI NVR1104H-4P , VIGI NVR2016H-16MP
Recent updates may have expanded access to feature(s) discussed in this FAQ. Visit your product's support page, select the correct hardware version for your device and check either the Datasheet or the firmware section for the latest improvements added to your product.
Surveillance equipment usually needs to work 24/7, and the video is mostly stored in the hard disk, so there are certain requirements for the hard disk. There are many types and models of hard drives on the market, and improper selection of hard drives may lead to abnormal video, video loss, or even damage to the NVR, to ensure that the video is more stable and reliable, you need to choose a hard drive compatible with the storage device.
Below are some suggestions to choose a suitable hard disk.
1. Choose a surveillance HDD.
The surveillance level HDD is designed for 24/7 continuously recording, which is suggested for VIGI NVR.
For example, the HDD provides from Western Digital has 6 types HDDs, including green, blue, black, red, purple and gold, among them purple level is surveillance HDD.
Color |
Typical Application |
Green |
home usage, HDD for file downloading |
Blue |
home usage, high performance and low-cost advantages |
Black |
video/photo editing/rendering and high-performance game console |
Red |
NAS environment |
Purple |
video surveillance storage, 24*7 continuous working design |
Gold |
Data Center |
For SEAGATE, SkyHawk series is the surveillance level HDD.
2. Recommended size and interface of NVR.
VIGI NVRs use SATA interface, which is common for the most of HDD and SSD.
To guarantee the life, we do suggest to use 3.5 inch HDD.
SSD has shorter life and more expensive, so HDD is suggested; 2.5 inch HDD is hard to fix in the NVR, so 3.5inch is better.
3. Choose a suitable volume.
The maximum volume of VIGI NVRs is 10TB, please choose a suitable capacity according to the environment, time, camera’s resolution and encoding type.
You can refer to the following two methods to calculate the capacity.
(1) Estimate via weekly storage:
In general, the monitoring scenario is relatively stable, the weekly capacity consumption is basically the same, so it is recommended to observe the capacity consumption in the past week to estimate.
HDD volume= Weekly storage * Time
(2) Calculate via VIGI Tool:
TP-Link has provided a quick tool to calculate the volume via some special parameters.
Link: https://www.tp-link.com/en/smb/vigi-tool/disk/
Note: The result is a reference value in an ideal condition, the real result will deviate inevitably.
4. Suggested HDD list.
The mainstream hard drive manufacturers now are mainly SEAGATE and Western Digital, we have tested some brands, below are the models we suggest use on VIGI NVR.
Brand |
Model |
Volume |
SEAGATE SkyHawk |
ST1000VX005 |
1TB |
SEAGATE SkyHawk |
ST2000VX015 |
2TB |
SEAGATE SkyHawk |
ST3000VX009 |
3TB |
SEAGATE SkyHawk |
ST4000VX007 |
4TB |
SEAGATE SkyHawk |
ST6000VX001 |
6TB |
SEAGATE SkyHawk AI |
ST10000VE001 |
10TB |
Western Digital Purple |
WD10EJRX |
1TB |
Western Digital Purple |
WD30PURZ |
3TB |
Western Digital Purple |
WD42EJRX |
4TB |
Western Digital Purple |
WD63EJRX |
6TB |
Western Digital Purple |
WD84EJRX |
8TB |
Western Digital Purple |
WD102PURZ |
10TB |
Note: The same model may have the different versions, so if you have experienced the compatible issue with above models, kindly contact us as soon as possible, many thanks!
