EAP230-Wall V1.20

Coming Soon

Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point

Dual-Band Wi-Fi 5: 867 Mbps on 5 GHz, and 300 Mbps on 2.4 GHz^†
2× Gigabit Ports: One for PoE input, one for RJ45 downlink.
Low Congestion: MU-MIMO allows multiple devices to receive data simultaneously, reducing congestion and improving speed.^‡
Complete In-Room Wi-Fi Coverage: Guaranteed strong signals and corner-to-corner Wi-Fi coverage up to 300ft² (25 ㎡).*
Flexible Deployment and Easy Setup: Supports 802.3af/at PoE for flexible installation with Omada SDN for one-click setup.
Advanced Features: Supports centralized cloud management and seamless roaming.^△
More Connections: Supports 200+ concurrent connections.**

Learn more about Omada Cloud SDN>

HARDWARE FEATURES
Interface	• Uplink: 1× Gigabit Ethernet Port • Downlink: 1× Gigabit Mbps Ethernet Port Notice: Non-Omada devices connected to the wired LAN ports will not be recognized by the Omada controllers, preventing users from viewing their connection status. To address this issue, connect those non-Omada devices to an Omada switch that links to the AP's wired LAN ports.
Physical Security Lock	No
Button	LED/Wi-Fi Button, RESET
Power Supply	802.3af PoE
Max. Power Consumption	7W
Dimensions ( W x D x H )	3.4 × 3.4 × 1.2 in (86.8 × 86.8 × 30.2 mm)
Antenna	Dual-Band Antennas: • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 3.6 dBi
Mounting	Wall Mounting (Screws included)
Hardware Watch Dog	Yes

WIRELESS FEATURES
Coverage	300 ft² (25㎡)^**
Concurrent Clients	200+^*
Wireless Standards	IEEE 802.11n/g/b/ac
Frequency	2.4 GHz and 5 GHz
Signal Rate	• 5 GHz: Up to 867 Mbps • 2.4 GHz: Up to 300 Mbps
Wireless Functions	• 16 SSIDs (Up to 8 SSIDs on each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS(WMM) • Seamless Roaming(802.11k/v)^△ • Load Balance • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client • MU-MIMO^‡ • Band Steering • Beamforming
Wireless Security	• Captive Portal Authentication^△ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Local LAN port based VLAN • Rogue AP Detection • 802.1X Support • 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
Transmission Power	• 7-20 dBm (2.4 GHz, EIRP) • 8-18 dBm (5 GHz, U-NII-1, EIRP)

Management Features
Omada App	Yes
Centralized Management	• Omada Hardware Controller • Omada Software Controller • Omada Cloud-Based Controller
Cloud Access	Yes. Require the use of an Omada controller.
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1,v2c
System Logging Local/Remote Syslog	Local/Remote Syslog
SSH	Yes
Web-based Management	HTTP/HTTPS
L3 Management	Yes
Multi-site Management	Yes
Management VLAN	Yes
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller.

OTHERS
Certification	CE, RoHS
Package Content	• EAP230-Wall • Installation Guide • Mounting Screws
System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing

For additional version information, please go to the support page.

^†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of internet service provider factors, network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.

^‡MU-MIMO capability requires client devices that also support MU-MIMO.

^*Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.

^**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.

^△These features require the use of an Omada controller.
